The Field Manager window opens and displays
the settings for the current connection.
7. Click the Setup Parameters tab at the bottom of the parameters window. A parameters window
opens.
8. Enable POut 5 (17, 18) and set the additional
parameters as required in the Uncorrected
Pulse Output Setup at the lower right of the
window.
Important: If your software does not have an
option to use POut for the uncorrected pulse
output, contact Eagle Research to get the correct
software version.
9. Enter the parameters shown in the Corrected
Pulse Output Setup section in the lower left of
the window.
10. Click Send All Changes.
11. Verify that all parameters are correct.
12. Click Disconnect.
Specific Meter Manufacturer Installation
100G Series Gas ERT Module Installation Guide, Remote Mount TDC-0824-017 24
Proprietary and Confidential
