A dialog box opens asking if you want to add the unit in
the Phone Book.
3.c Click Close at the bottom of the window.
3.d Confirm the Meter was added to the Phone Book.
3.e Set up the corrected or uncorrected parameters.
3.f.1 From the Talk to Unit tab, select Setup > Default.
3.f.2 Set the following Default Setup Group
parameters:
• Enter the desired Cor. Volume Unit parameter. Set
Cor. Pulse Volume to the same number of units.
• For Output Pulse Spacing, enter the largest
number over 285mS that works for your application.
(Itron recommends a setting of 350mS.)
• For Output Pulse Width, enter the largest number
over 28mS that works for your application. (Itron
recommends a setting of 40mS.)
3.f.3 Click Send at the bottom of the page.
3.f.4 Select Current Page.
ECM2
®
programming
4. Set the ECM2 output pulse spacing to 750ms for operation with the 100G remote ERT module.
Output spacing represents an off-time between pulses.
Specific Meter Manufacturer Installation
100G Series Gas ERT Module Installation Guide, Remote Mount TDC-0824-017 61
Proprietary and Confidential
