Operation: CP1SD/T/L Version
CENTRON® Polyphase Meter Technical Reference Guide 41
The following tables show items programmable for display in the modes indicated.
All of the display items in the next two tables may be selected by TOU Rate. They also may
be selected from the four Self Read buffers, the two Demand Reset Snapshot buffers, and
Last Season Self Read buffer.
Energy Data Display Items
Display Mode
Energy Data Display Item
Normal Alternate Test Toolbox 1
Wh (delivered, received, net, uni-
directional)
X X X
Varh (delivered [lag], received [lead], Net,
net delivered, net received, Q1, Q4)
X X X
VAh (delivered, received; arithmetic &
vectorial)
X X X
VAh lag (vectorial) X X X
Qh (delivered, received) X X X
Vh (Phase A, Phase B, Phase C,
Average)
X X
Ah (Phase A, Phase B, Phase C) X X
V
2
h Aggregate X X
A
2
h Aggregate X X
Demand Data Display Items
Display Mode
Demand Data Display Item
Normal Alternate Test Toolbox2
W Delivered (Max, Present, Previous,
Projected, Cumulative, Continuous
Cumulative)
X X X
W Received (Max, Present, Previous,
Projected, Cumulative, Continuous
Cumulative)
X X X
W Net (Max, Present, Previous,
Projected, Cumulative, Continuous
Cumulative)
X X X
W Uni-directional (Max, Present,
Previous, Projected, Cumulative,
Continuous Cumulative)
Var Q1, Var Q4 (Max, Present, Previous,
Projected, Cumulative, Continuous
Cumulative)
X X X
Var Delivered [lag: Q1+Q2] (Max,
Present, Previous, Projected, Cumulative,
Continuous Cumulative)
X X X
