Operation: CP1SD/T/L Version
42 CENTRON® Polyphase Meter Technical Reference Guide
Display Mode
Demand Data Display Item
Normal Alternate Test Toolbox2
Var Received [lead: Q3+Q4] (Max,
Present, Previous, Projected, Cumulative,
Continuous Cumulative)
X X X
Var Net
VA Delivered [arithmetic or vectorial]
(Max, Present, Previous, Projected,
Cumulative, Continuous Cumulative)
X X X
VA Received [arithmetic or vectorial]
(Max, Present, Previous, Projected,
Cumulative, Continuous Cumulative)
X X X
VA Lag (Max, Present, Previous,
Projected, Cumulative, Continuous
Cumulative)
X X X
Max A (per phase: A, B, C) X X
PF Average X X
Min P.F. X X
Coincident Demands (up to 4) X X
Instantaneous Data Display Items
Display Mode
Instantaneous Data Display Item
Normal Alternate Test Toolbox3
Instantaneous W X X X
Instantaneous Var X X X
Instantaneous VA (arithmetic & vectorial) X X X
Instantaneous Volts (A, B, C) X X
X
Instantaneous Amps (A, B, & C) X X
X
Instantaneous P.F. X X
Instantaneous Frequency (Hz) X X
Instantaneous Current Phase Angles (A, B, C)
X
Instantaneous Voltage Phase Angles (A, B, C)
X
Informational Data Display Items
Display Mode
Informational Data Display Item
Normal Alternate Test Toolbox4
Calibration Date & Calibration Time X X
Cold Load Pickup Outage Time X X
Current Transformer Ratio X X
Current Date, Day & Current Time X X
