ITRON RR16 User Manual

8
SPRING RANGE OF INTEGRATED SSV
SAV 033 OPSO (wdo = 40 – 450 mbar)
Type Spring range wdso Spring-No. Colour Wire-Ø (mm)
SAV 033
40 – 70 mbar
50 – 150 mbar
140 – 450 mbar
955-200-22
955-200-23
955-200-24
red
blue
green
1.4
1.6
2.6
SAV SL-IZN.1 / M.1 OPSO (wdo = 0,035 – 1.7 bar)
Type Spring range wdso Spring-No. Colour Wire-Ø (mm)
SL- IZN.1
35 – 250 mbar
200 – 800 mbar
955-202-36
955-202-37
red
green
1.8
2.5
SL- IZM.1 0,6 – 1,7 bar 955-202-38 yellow 3.6
SAV 022 OPSO & UPSO (wdo = 0,020 – 1.7 bar and wdu = 10 – 220 mbar)
Type Spring range wdso Spring range wdsu Spring-No. Colour Wire-Ø (mm)
SAV 022,
OPSO
pdso
20 – 60 mbar
50 – 120 mbar
100 – 450 mbar
0,35 – 1,0 bar
0,8 – 1,7 bar
955-200-22
955-200-23
955-200-24
955-203-41
955-203-42
red
blue
green
black
yellow
1.4
1.6
2.6
3.2
4.0
SAV 022,
UPSO
pdsu
10 – 50 mbar
40 – 120 mbar
100 – 220 mbar
955-200-32
955-203-51
955-203-76
red
brown
yellow
0.8
1.25
1.6
SAV SID-N and -M OPSO & UPSO (wdo = 0,020 – 1.7 bar and wdu = 5 – 220 mbar)
Type Spring range wdso and wdsu Spring-No. Colour Wire-Ø (mm)
SAV SID-N
OPSO & UPSO
pdso + pdsu
5 – 110 mbar
80 – 250 mbar
955-201-65
955-201-66
black
green
3.2
4.0
SAV SID-M
OPSO & UPSO
pdso + pdsu
100 - 230 mbar
200 – 470 mbar
0,45 – 1,5 bar
1,0 – 1,7 bar
955-201-65
955-201-66
955-201-67
955-201-68
black
green
brown
black
3.2
4.0
5.6
6.0
LIMITING VALUES OF SET POINTS FOR SSV SL-IZ…; 033; 022 AND SID*
With RR 16 gas pressure regulators, only the diaphragm size of the regulator actuating drive determines the highest shut-off pressure
pdo of the SSV.
Actuating Drive Body-Ø Maximal set point pdso of SSV
12“ diaphragm housing 0.3 bar above pds
8“diaphragm housing 0.6 bar above pds
* In combination low-pressure / medium-pressure measuring unit (SSV-SID-NM) the upper switching point must not exceed 1,5 bar!
