164
360P
356E
100
357A
6.4.7 Remove the suction sideplate
WARNING:
Sideplates are heavy
. Use the proper support to avoid personal injury.
This procedure only applies to models that have an open impeller or a Shearpeller
TM
.
1. Remove the hex nuts (357A) from the sideplate studs (356E).
2. Remove the sideplate (176) from the casing (100) using a pry bar in the provided slot.
6.4 Disassembly
82 Models 3180, 3181, 3185, and 3186 Installation, Operation, and Maintenance Manual
