System Modules
Pressure Sensor P/N: 4600-905
The pressure sensor has several great
features, and still maintains a simplicity in
design. The sensor should not require
adjustmentssincethethresholdlevelsareset
atthefactory.Thesensorconstantlymonitors
pressureand triggersan error on the system
if the air pressure drops below the
predetermined level. Digitally,
the pressure
is updated three (3) times a second. In
conjunction to the digital readout, the
bargraph displays the pressure and
fluctuations.
