Ivoclar Vivadent Programat EP 5010 - Page 5

5
21 Insulation
22 Firing plate
23 Firing plate holder
24 Frame plate
25 QTK2 heating muffle
26 Sealing rims of furnace head
28 Sealing surface
27 Infrared camera
List of parts
32 Rating plate
33 Vacuum pump fuse
37 Connection cover
36 Covering hood for head
opening mechanism
38 Screw for connection cover
C Screw for
press drive cover
39 Air vents rear panel
40 Heating element fuse
41 Vacuum hose connection
42 Vacuum hose
34 Vacuum pump socket
35 Power cord for vacuum pump
29 On / Off switch
30 Power socket
31 Power cord
