23
For safety reasons, the
heating muffle may
only be changed by a
certified Ivoclar Viva-
dent Service Centre
(Err 23 and Err 24).
Clearing measures for Err 22, if
the motor for the furnace head
is in an inappropriate position
(provided that the ‘close furnace
head’ key is not defective):
Situation A
The furnace has been switched
on before the furnace head (1) is
mounted (initial start-up or after
maintenance of the furnace
head):
Press STOP to acknowledge the
error message. After that, press
the ‘close furnace head’ key.
Secure the furnace
head screw
(see Chapter 4).
Situation B
Error message Err 22 appears if
the furnace head (1) is correctly
mounted.
Remove any objects that are
possibly located between the
furnace head (1) and the
furnace base. Press STOP to
acknowledge the error message.
Then, press ‘close furnace head’
key. If Err 22 reappears, press
STOP again and try the ‘close
furnace head’ key again. It may
be necessary to repeat this
procedure more than once.
Do not use the ‘open furnace
head’ key. Should be furnace
head be opened during this
process, it is not important,
since the movements of the
furnace head are normally
self-adjusting.
Situation C
Same as situation B, but with
the error occurring immediately
after switching on the furnace,
i.e. during the self-diagnosis.
Same as situation B.
Additionally, the furnace has
to be switched off and on again
at the end of the procedure to
make sure that the self-diagnosis
is repeated.
Fehler Beschreibung Hinweise für den Anwender
Err 27 Furnace head does not open after the initial start-up. The opening process might be obstructed by external, mechanical
influences. If this is not the case, contact your local Ivoclar
Vivadent Service Centre. This error can only be acknowledged by
switching the furnace off an on again.
Err 28 Furnace head has been moved manually or the opening process Move the furnace head (1) only by means of the corresponding
has been obstructed. keys.
*Err 29 Temperature alert (temperature >= approx. 1300 °C (2372 °F). If this error message appears, the heater is switched off for safety
reasons. The furnace head (1) opens and the keypad does not
work. If you want to close the furnace head (1) despite this error,
proceed as follows:
– Switch off the furnace and wait for 20 s.
– Switch the furnace on again and wait until the furnace head
is closed.
Errors in the supply unit
Err 30 Heating relay does not respond. Contact your local Ivoclar Vivadent Service Centre.
Err 31 Vacuum valve does not respond. Contact your local Ivoclar Vivadent Service Centre.
Err 32 Vacuum has been measured over a prolonged period of time – The vacuum valve is probably stuck or dirty.
the furnace head cannot be opened (after the initial start-up).
Err 33 The necessary vacuum has not been reached with 1 min. Check the following items:
– Is the firing chamber tight (is the sealing surface clean)?
– Is the vacuum hose connected?
– Is the vacuum pump connected?
– Is the fuse (25) in order?
Err 34 Error in the electronic component for the supply unit. Contact your local Ivoclar Vivadent Service Centre.
Err 35 Error in the electronic component for the supply unit. Contact your local Ivoclar Vivadent Service Centre.
Err 38 Error in the electronic component for the muffle controls. Contact your local Ivoclar Vivadent Service Centre.
Errors in the control unit
Err 40 Indicator for the electronic components defective. Contact your local Ivoclar Vivadent Service Centre.
Err 42 Error in the program memory. Contact your local Ivoclar Vivadent Service Centre.
Err 43 Write error in the firing program memory. Contact your local Ivoclar Vivadent Service Centre.
Err 44 Read error in the firing program memory. Contact your local Ivoclar Vivadent Service Centre.
Err 45 Checksum error in the firing program memory. Checksum of a firing program invalid; the firing program will be
initialized with the original values.
Err 46 Error when accessing the real time clock.
Err 47 The firing program has recognized an invalid situation Conduct a power reset.
in the program sequence.
Errors in the analog module
Err 50 Sensor calibration is not valid. Furnace can no longer be operated.
Err 51 Error in the microprocessor of the analog module. Contact your local Ivoclar Vivadent Service Centre.
Err 52 Error in the calibration memory of the analog module. Contact your local Ivoclar Vivadent Service Centre.
Err 54 Error in the electronic component for the temperature measurement. Contact your local Ivoclar Vivadent Service Centre.
Err 55 Analog module cannot respond. You probably have a poor power supply.
Err 56 Temperature in the furnace base is lower than 1 °C (33.8 °F). Increase the temperature in the furnace base.
Further error messages
*Er:71 Thermocouple defective at initialization. Contact your local Ivoclar Vivadent Service Centre (2)
*Err 72 Temperature leap. Contact your local Ivoclar Vivadent Service Centre (2)
*Err 73 Inadequate performance of the heater. Contact you local Ivoclar Vivadent Service Centre (2)
*Furnace head opens when this error occurs.
1)
No operating error.
2)
If this error message appears, the heater is switched off for safety reasons. The furnace head
opens and the keypad is inactivated. This error cannot be acknowledged with STOP.
The furnace has to be switched off and on again.
