MONITOR DESCRIPTION
Model 3150-B Operation Manual
8
MONITOR DESCRIPTION
The Model 3150-B Cardiac Trigger Monitor is an easy to use color monitor that display a patient’s ECG waveform
and heart rate. The ECG lead displayed can be selected from Leads I, II or III. In addition high and low heart rate
alarm limits can be adjusted to bracket the patient’s heart rate so that a violation of these limits produces an audible
and visual indication of the violation. The color display has a single trace, large Heart Rate numbers and
alphanumeric characters for other data, alarm messages, menus and user information.
The Model 3150-B monitor is intended primarily for use on patients in applications requiring precision R-wave
synchronization such as timed imaging studies.
The Model 3150-B has an RJ45 “Ethernet” connector that provides two way communications between the monitor
and the CT console for the transfer of ECG data and trigger timing data and the receipt of patient identification
information. This function will only operate when the Model 3150-B is electrically connected to a CT-scanner and
CT console.
The Model 3150-B has a USB drive that allows the operator to store and retrieve ECG data on a USB memory stick
device. The Model 3150-B also has special hardware and software that allows for the measurement of ECG
electrode impedance, prior to, during and after the CT scan.
An integral recorder is standard on the Model 3150-B, set up of recorder functions are made through the monitor
menus.
Summary of main options__________________ _____
Model USB Port Chart
Recorder
Impedance
Measurement
3150-B Standard Standard Standard
The Model 3150-B is suitable for use in presence of Electro-surgery.
The Model 3150-B is not intended for use with any other physiological monitoring unit.
The Model 3150-B is restricted to use on one patient at a time.
The Model 3150-B is not intended for home-care patient monitoring.
