Ivy Biomedical Systems 3150-B User Manual

P/N 3044-00-16 Rev.00 Page 1 of 1
17-December-2008
ADDENDUM 2
Model 3100-B / 3150-B Installation Instructions
1. Remove the new monitor from the shipping carton.
2. Line up the new monitor and its adapter plate with the mounting plate on the roll stand. Pull
down the safety pin and slide the monitor on the adapter plate. Release the safety pin and
make sure safety pin is engaged in the adapter plate (The adapter plate has a hole to allow the
safety pin to secure the monitor).
3. Before the monitor is plugged into any power source verify visually that the Line Voltage
Selector switch displays the appropriate voltage range for your location.
Line Voltage
Selector Switch
