Page 48 Engine Data Management
window if no ATIS available) by tapping/holding the LF button.
The range is +/- 3 in HG.
OR
B. Airport above sea level: the table below shows MAP for a given
field elevation (down the left side of the table) and altimeter
setting (along top row of the table). Find the closest entry in the
table to your field elevation and current altimeter setting.
Interpolate if necessary. Adjust the MAP gauge digital display by
tapping/holding LF button. The range is +/- 3 in. HG.
Alt setting->
field elev.
29.0 29.2 29.4 29.6 29.8 29.9 30.0 30.2 30.4 30.6 30.8 31.0
0 29.0 29.2 29.4 29.6 29.8 29.9 30.0 30.2 30.4 30.6 30.8 31.0
1000 28.0 28.2 28.4 28.5 28.7 28.8 28.9 29.1 29.3 29.5 29.7 29.9
2000 27.0 27.1 27.3 27.5 27.7 27.8 27.9 28.1 28.3 28.5 28.6 28.8
3000 26.0 26.2 26.3 26.5 26.7 26.8 26.9 27.1 27.2 27.4 27.6 27.8
4000 25.0 25.2 25.4 25.6 25.7 25.8 25.9 26.1 26.3 26.4 26.6 26.8
5000 24.1 24.3 24.5 24.6 24.8 24.9 25.0 25.1 25.3 25.5 25.6 25.8
6000 23.2 23.4 23.6 23.7 23.9 24.0 24.0 24.2 24.4 24.5 24.7 24.8
7000 22.4 22.5 22.7 22.8 23.0 23.1 23.1 23.3 23.5 23.6 23.8 23.9
For this method, do not set MAP to the local altimeter
(Kollsman window) setting since that setting is the pressure
at sea level, and is not the same as your field elevation
pressure.
7. Tap the STEP button to save.
Section 9 - Programming use of Factory Original TIT Probe
If your aircraft is using the factory original TIT probe and gauge, you
should calibrate the EDM for that probe. The factory original TIT probe
must be a type K and the leads must be wired red-to-red and yellow-to-
yellow. Both the EDM and factory original gauge may be used
concurrently. Due to the high input impedance of the EDM instrument, it
will not affect the accuracy of the factory installed probe or gauge. In
normal cruise flight, record the difference between the factory installed
TIT gauge and the EDM TIT reading: TIT gauge _____ EDM _____.
If you haven’t already done so, start the pilot programming procedure,
by simultaneously holding the STEP and LF buttons for a few seconds
until you see the word PROGRAM for two seconds.
Tap STEP
to advance
to the next
item
Tap the LF button to
sequence through
these values
Comments
PROGRAM Appears for two seconds.
