Page 36 Engine Data Management
appear in the output data file. The aircraft id can be your aircraft
registration number or your name. Initially the aircraft ID is set to the
EDM's serial number.
You may change the record interval from 2 to 500 seconds, even in flight.
When you change the interval in flight, the current flight file is closed,
and a new flight file is created with the new record interval.
At power on, the EDM will execute its self test and then display the date
(e.g., I I. I2.0 I), the time (I3.26), the percentage of memory
filled since the last save (FULL 24), and the Aircraft ID.
Downloading data to the Palm Computer
The examples shown here are specifically for the Palm™ computer and a
PC running Windows® 98. J. P. Instruments provides an optional cable
to interface to the Palm cradle cable or travel cable. J. P. Instruments has
a downloadable data transfer application program for the Palm series
called EzPalm™.
Downloading the EzPalm Program from the Internet
Go to our web page www.jpinstruments.com, go the Home page and then
go to the downloads page. Double click on EZPALM2.ZIP. When the
File Download window appears select Save this file to disk. Save the file
to folder C:\Palm\Add-on.
Using Windows Explorer, go to the folder C:\Palm\Add-on and double
click on the file name EZPALM2.ZIP. In the new Windows Explorer
window that opened, double-click on EZSAVEP.EXE. Select Extract
All. Accept the default directory C:\Palm\Add-on\EZPALM2 and
select Next. Answer Yes and select Finish.
Installing EzPalm on the Palm Computer
Do one of the following:
1. Using Windows Explorer, go to directory
C:\Palm\Add-on\EZPALM2 and double-click on EzPalm.prc. Click
Done, Click OK. Or
2. From the Palm Desktop program click on the Install button. Click Add,
select directory C:\Palm\Add-on\EZPALM2, select EzPalm.prc, Click
Open, Click Done, Click OK.
