26
6-2 Connectors & Functions
Connector Function
CN1 Front I/O board
CN2 Inverter connector
CN3 LVDS connector
CN6 System FAN connector
CN7 LPT port connector
CN8 Speaker & MIC connector
CN9 40pin external connector
CN10 HDD LED connector
CN11 Power LED connector
CN12 SATA power connector
CN13/14 USB port (internal)
CN15 PS2 keyboard connector
CN16 LPT touch
CN17 MSR connector
CN18 COM5 (touch) connector
CN19 Wide Range
CN20 Power button (internal)
CN21 LCM connector
CN22 POS325 51pin connector
PWR1/PWR2 DC Jack
RJ11_1 Cash drawer connector
RJ45_1 LAN connector
RJ45_2 COM1/ COM2
RJ48_1 COM3
DDR3_A1 DDR3 SO-DIMM
SATA0/SATA2 SATA
USB1/USB2 USB2.0
USB3 USB3.0
VGA1 CRT connector
SW1 Power button
MINI_PCIE1 MINI PCIE
JP1 Inverter select
JP4 LCD ID setting
JP6 Cash drawer power setting
JP7 Touch connector
