J2 240 - Page 34

28
7 1024 x 600 18 Single LVDS Panel
8 1280 x 1024
24 Dual LVDS Panel
9 1440 x 900 24 Dual LVDS Panel
15 1920 x 1080
24 Dual LVDS Panel
CRT
COM1/COM2/COM3 Power Setting
COM1, COM2 and COM3 can be set to provide power to your serial device.
The voltage can be set to +5V or
+
12V in the BIOS.
1. Power on the system, and press the <DEL> key when the system is booting up
to enter the BIOS Setup utility.
2. Select the Advanced tab.
3. Select VGA/COM Power Configuration Ports and press <Enter> to go to
display the available options.
