ProTIG 220/300 AC/DC
Operating manual Page 24
Supply voltage, 50/60 Hz
400V +/- 15%, 3 Phase
Main fuse 16A
Max. power draw 9,6 kVA
Kind of current AC or DC
Power factor / cos
φ
0,95 / 0,99
TIG Electrode
Set-point range Step less 5 - 300A 10 - 250A
Operating voltage 10 – 22V 20 – 30V
Open circuit voltage 10 V 100 V (with VRD <13V)
Duty cycle x % (40°C) 300A / 22V (35%) 250A / 30V (40%)
Duty cycle 60 % (40°C) 250A / 20V 220A / 28,8V
Duty cycle 100 % (40°C) 210A / 18,4V 190A / 27,6V
Max. main current I
eff
= 8A, I
max
= 14A I
eff
= 9A, I
max
= 14A
System of protection IP 23
Insulation class F
System of cooling F
Weight power source solo 19 kg
Dimensions L x B x H (mm) complete 520 x 190 x 415
Authorised for welding under
increased electrical hazard
Manufactured in accordance with
European Standards EN 60 974-1 and EN 60 974-10
Cooling unit KG 11 – 400V KG 12 – 400V
Supply voltage, 50/ 60 Hz 400V 400V
Fuse 2A slow 1A slow
Max. power draw 0,3kW 0,2kW
Pump power max. 3,3 bar 3,2 bar
Cooling performance 1000 W 500W
System of protection IP 23 IP 23
Weight 25 kg (fully fueled) 12,5 kg (fully fueled)
Tank capacity 8 ltr. 2,5 ltr
Water connections quick coupling DN5 quick coupling DN5
Dimensions L x B x H (mm) 640 x 260 x 230 540 x 190 x 260
Generator operation:
The generator must have 30% more power as the welding unit.
The generator for this unit must have 13kVA.
A generator with less power will damage the Jäckle welding unit as well as the generator himself
and is disallowed.
