ProTIG 220/300 AC/DC
Operating manual Page 23
18. Technical data
Supply voltage, 50/60 Hz
230V +/- 15%, 1 Phase
Main fuse 16A
Max. power draw 6,3 kVA
Kind of current AC or DC
Power factor / cos
φ
0,99 / 0,99
TIG Electrode
Set-point range Step less 5 - 220A 5 - 180A
Operating voltage 10 – 18,8V 20 – 27,2V
Open circuit voltage 10 V 100 V (with VRD <13V)
Duty cycle 30 % (40°C) 220A / 18,8V 180A / 27,2V
Duty cycle 60 % (40°C) 180A / 17,2V 150A / 26V
Duty cycle 100 % (40°C) 140A / 15,6V 120A / 24,8V
Max. main current I
eff
= 13A, I
max
= 24A I
eff
= 16A, I
max
= 27A
System of protection IP 23
Insulation class F
System of cooling F
Weight power source solo 18 kg
Dimensions L x B x H (mm) complete 480 x 190 x 415
Authorised for welding under
increased electrical hazard
Manufactured in accordance with
European Standards EN 60 974-1 and EN 60 974-10
Cooling unit KG 11 – 230V KG 12 – 230V
Supply voltage, 50/ 60 Hz 230V 230V
Fuse 2A slow 1A slow
Max. power draw 0,3kW 0,2kW
Pump power max. 3,3 bar 3,2 bar
Cooling performance 1000 W 500 W
System of protection IP 23 IP 23
Weight 25 kg (fully fueled) 12,5 kg (fully fueled)
Tank capacity 8 ltr. 2,5 ltr.
Water connections quick coupling DN5 quick coupling DN5
Dimensions L x B x H (mm) 640 x 260 x 230 540 x 190 x 260
Generator operation:
The generator must have 30% more power as the welding unit.
The generator for this unit must have 8,2kVA.
A generator with less power will damage the Jäckle welding unit as well as the generator himself
and is disallowed.
