Jackle ProTIG 220 DC - Quick View DC and AC Control

ProTIG 220/300 AC/DC
Operating manual Page 28
A
V
A
V
1- Display Volt/Ampere
I
2
t
3 - Welding mode
30 - 2 cycle
31 - 4 cycle
32 - Current I 2
33 - Spot
21. Quick view DC and AC Control
Quick view DC Control:
AUTO
MAN
SPEED
8 - Pulse type
80 - Synergic Pulse
81 - Fast Pulse
82 - Slow Pulse
2- Welding process
21 - DC current
with HF ignition
22 - DC current
without HF ignition
23 - Electrode
welding
f
lb
lp
1
I
2
HOTSTART
ARCFORCE
T
b
T
p
SU SD
IS IE
PULS
I
4 - Functions
- Gas pre flow time / Gas post flow time
IS - Start current
SU - Slope Up time
I - Main current
I - Current I2 (only in I mode)
lb - Base current (only in Pulse mode)
lp - Pulse current ( )
Tb - Base current time
Tp - Pulse current time
f - Pulse frequency
SD - Slope down time
IE - Final welding current
1
2 2
only in Pulse mode
(only in Pulse MAN mode)
(only in Pulse MAN mode)
(only in Pulse AUTO/SPEED mode)
