07610-002-41-09-F
5
ELECTRICAL REQUIREMENTS
NOTE 1: MCA (Minimum Circuit Ampacity) = 125% x Largest Motor + FLA of all other motors + all other loads.
NOTE 2: MOP (Maximum Overcurrent Protective Device) = 225% x Largest Motor + FLA of all other motors + all other loads.
All electrical ratings provided in this manual are for reference only. Always refer to the machine data plate to get exact
electrical information for this machine. All electrical work performed on machines should be done in accordance with ap-
plicable local, state, territorial and national codes. Work should only be performed by qualifi ed electricians and authorized
service agents.
Where applicable, heating element amperage draws have been adjusted for the assumed input voltage. Jackson assumes
incoming voltages will be either 208 or 230 volts. Some heating elements used in the machines are rated for other voltages,
such as 240 volts. Always verify the amperage draw of the machine in operation when sizing circuit protection.
If the dishmachine is equipped with the optional rinse heater, note the rinse heater may have its own electrical connection
and therefore require a separate service. Amperage loads for motors and heaters are indicated on the machine data plate.
The electrical confi gurations of the 10 series of machines are as follows:
Available Electrical Characteristics:
• 10A 208 - 220 V, 60 HZ, single phase
• 10AB 208 - 220 V, 60 HZ, single phase
• 10AB/10U 208 - 220 V, 60 HZ, three phase
• 10AB/APRB/10U 208 - 220 V, 60 HZ, single phase
• 10AB/APRB/10U 208 - 220 V, 60 HZ, three phase
MODEL 10
Electrical Characteristics
Model Volts Phase Hertz Amps
10A 208 1 60 8.23
10A 220 1 60 8.23
10AB/10U 208 1 60 38.8
10AB/10U 208 3 60 25.6
10AB/10U 220 1 60 37.2
10AB/10U 220 3 60 24.6
10APRB 208 1 60 43.4
10APRB 208 3 60 30.2
10APRB 220 1 60 41.8
10APRB 220 3 60 29.2
INSTALLATION
