07610-002-41-09-F
17
16. Replace the lower large manifold and fi ll the raceway fully with the bearings,
then remove one.
17. Replace the upper small manifold and fi ll raceway fully with bearings, then
remove one.
18. Replace the wash cap by turning clockwise onto the center shaft and fi nger-
tighten.
19. Turn the wash cap counter-clockwise by a 1/4” turn and tighten the allen set
screw.
20. Rotate the manifolds in opposite directions and see if they rotate freely. (Select
the longest tube in the bottom manifold and make sure it moves up and down at
least 1/8” and no more than 1/4”.)
21. Close the hood doors and refi ll the dishwasher.
22. Run through several cycles and recheck the wash manifolds for easy
movement. Adjust if necessary.
SERVICE
PROCEDURES
RINSE/WASH HEAD ASSEMBLIES
RINSE/WASH
HEAD ASSEMBLIES
(CONTUNIED)
