Jackson 10 Series User Manual

07610-002-41-09-F
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Hood Assembly N/A
2 1 Motor and Pump Assembly 05700-002-60-91
1 Motor and Pump Assembly (APRB only) 05700-002-60-91
3 1 Shroud (without holes for gauges) 05700-000-24-77
3 1 Shroud (with holes for gauges) 05700-002-60-36
4 1 Control Box Support Bracket 05700-000-24-76
5 4 Bullet Feet 05340-108-01-03
6 1 Outlet Connector 05700-002-60-92
7 1 Complete Control Box Assembly N/A
8 1 Vacuum Breaker Assembly N/A
9 1 Rinse Tank Assembly 05700-000-24-84
9 1 Rinse Tank Assembly (APRB Only) 05700-000-24-80
10 1 Inlet Connector 05700-002-60-93
11 1 Incoming Plumbing Assembly 05700-000-15-25
12 1 Tub Weldment Assembly 10AB 05700-000-57-73
1 Tub Weldment Assembly 10AB (9” shorter leg)/10U 05700-002-60-94
1 Tub Weldment Assembly 10APRB 05700-000-57-74
1 Tub Weldment Assembly 10APRB (9” shorter leg) 05700-002-62-01
