07610-002-41-09-F
40
PARTS
CONTROL BOX ASSEMBLY
ITEM QTY DESCRIPTION Mfg. No.
1 1 Control Box Panel with Decal 09905-500-07-10
2 1 Timer 05945-303-19-00
3 1 Bracket, Timer Mounting 05700-000-34-28
4 4 Screw, 10-32 x 3/8” Phillips Truss Head 05305-173-12-00
5 4 Locknut, 10-32 S/S Hex with Nylon Insert 05310-273-01-00
6 3 Light, Pilot 05945-504-02-18
7 1 Block, 9 Position Terminal 05940-500-06-19
8 1 Decal, Terminal Block 09905-100-87-62
9 2 Screw, 8-32 x 3/8” Round Head 05305-172-02-00
10 6 Lockwasher, #8 External Tooth 05311-272-01-00
11 2 Nut, Hex 8-32 05310-272-01-00
12 1 Switch, Rinse 05930-301-20-18
13 1 Switch, Wash 05930-301-21-18
14 2 Switch, Master 05930-301-22-18
15 1 Switch, Start 05930-301-23-18
16 1 Decal, Schematic, 10A 09905-002-57-63
16 1 Decal, Schematic, 10AB/10U, 1 Phase 09905-105-33-59
16 1 Decal, Schematic, 10AB/10U, 3 Phase 09905-105-34-47
16 1 Decal, Schematic, 10APRB, 1 Phase 09905-105-33-62
16 1 Decal, Schematic, 10APRB, 3 Phase 09905-105-34-50
17 1 Panel, Control Box Front and Bottom 05700-000-24-30
18 1 Circuit Breaker, 15 Amp 05925-105-10-01
19 1 Plate, Circuit Breaker 05927-113-13-01
20 2 Screw, 8-32 x 1/4” Round Head Slotted 05305-172-01-00
21 1 Control, Water Level (2 for APRB option) 06680-200-01-19
22 4 Screw, 6-32 x 3/4” Phillip Pan Head (8 for APRB option) 05305-011-37-05
23 4 Lockwasher, #6 External Tooth (8 for APRB option) 05311-271-02-00
24 2 Block, Terminal (1 Phase Units) 05940-500-02-19
24 3 Block, Terminal (3 Phase Units) 05940-500-02-19
25 1 Track, Terminal Block, 3 5/16” 05700-000-43-60
26 1 Ground Lug 05940-200-76-00
27 1 Locknut, 10-24 S/S Hex with Nylon Insert 05310-373-01-00
28 1 Decal, Ground 09905-011-86-86
29 1 Decal, Copper Conductors 09905-011-47-35
30 1 Control Box Weldment, Right Hand 05700-000-27-99
30 1 Control Box Weldment, Left Hand 05700-002-49-62
31 3 feet Rubber Strip, 1/2” x 1/8” 05330-100-10-00
32 1 Contactor (1 Phase Units) 05945-002-74-20
32 1 Contactor (3 Phase Units) 05945-109-06-69
32 N/A Not used on 10A N/A
