TUB ASSEMBLY
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Wire Spring Ring 05315-700-03-00
2 1 Cable Assembly 03020-201-09-01
3 1 Support, Rack Weldment 05700-000-13-43
4 1 Intake Strainer 05700-000-03-02
5 1 Bulk Head Plug 04730-609-05-00
6 1 Casting, Rinse Feed 05700-000-16-47
7 1 Gasket, Rinse Feed 05330-200-02-06
8 2 Bolt, Flat Head 05305-174-14-00
9 2 Bolt, 5/16"-18 x 1" S/S Hex 05305-275-06-00
10 2 Bolt, 1/4"-20 x 1/2" S/S Hex 05305-274-02-00
11 1 Locknut, 6-32 S/S Hex with Nylon Insert 05310-373-03-00
12 1 Cover, Lundy Probe 05700-000-31-73
13 2 Locknut, 10-24 S/S Hex with Nylon Insert 05310-373-01-00
14 1 Gasket, Lundy Probe Cover 05330-200-25-00
1 Rinse Arm Assembly 05700-000-28-68
15 1 Rinse Arm 05700-000-28-68
16 2 Rinse Arm Nylon Washer 05311-369-08-00
17 1 Rinse Arm Hex Bushing 05700-000-28-65
18 1 Rinse Arm Snap Ring 05340-112-02-11
19 1 Rinse Feed Pipe Weldment 05700-002-60-96
20 1 Set Screw, 10-24 x 1/2" 05305-473-02-00
21 1 Wash Head Cap 05700-000-10-12
22 57 Ball Bearing, 1/4" S/S 03110-100-03-24
23 1 Threaded Shaft 05700-000-11-01
24 1 Small Manifold Washarm 05700-000-57-69
25 1 Large Manifold Washarm 05700-000-57-70
26 1 Casting, Wash Head Bottom 05700-000-10-36
27 1 Locknut, 1/4"-20 S/S Hex with Nylon Insert 05310-374-01-00
28 1 Bolt, 1/4"-20 x 2 3/4" S/S Hex Head 05305-274-13-00
29 1 Overfl ow Strainer 04730-017-15-05
30 1 O-ring 05330-400-05-00
31 1 Stem 05305-171-13-00
32 1 Inside Porcelain 05970-604-02-00
33 1 Rubber Insert 05970-604-03-00
34 1 Outside Porcelain 05970-604-04-00
35 1 Washer, #6 Paper 05970-604-01-00
36 2 Nut, 6-32 S/S Hex 05310-271-01-00
37 1 Lockwasher, #6 External Tooth 05311-271-02-00
