07610-002-41-09-F
48
BOTTOM VIEW OF TUB ASSEMBLY
ITEM QTY DESCRIPTION Mfg. No.
1 1 Shroud, (Without Holes For Gauges) 05700-000-24-77
1 Shroud, (With Holes For Gauges) 05700-002-60-36
2 2 Gauge, Temperature 06685-111-68-48
3 1 Decal, Wash and Rinse Temperature 09905-100-43-21
4 1 Control Box Support Bracket 05700-000-24-76
5 4 Bolt, 5/16"-18 x 1" S/S Hex 05305-275-06-00
6 4 Washer, 5/16" S/S Flat 05311-175-01-00
7 1 Thermostat Box Weldment 05700-000-59-70
8 3 Locknut, 1/4"-20 S/S Hex with Nylon Insert 05310-374-01-00
9 1 Bulk Head Plug 04730-609-05-00
10 1 Element, Wash Heater 04540-100-11-10
11 4 Washer, 1/4"-20 S/S 05311-174-01-00
12 4 Lockwasher, 1/4" Spring 05311-274-01-00
13 4 Nut, 1/4"-20 S/S Hex 05310-274-01-00
14 1 Cover, Wash Heater 05700-000-60-57
15 1 Gasket, Wash Heater 05330-011-61-34
16 1 Clamp, 1/8” Nylon 05975-601-10-15
17 1 Locknut, 6-32 S/S Hex with Nylon Insert 05310-373-03-00
BOTTOM VIEW ASSEMBLY (10APRB SHOWN FOR REFERENCE)
PARTS
