07610-002-41-09-F
50
WASH TANK CONNECTION
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Gasket, Wash Heater 05330-011-61-34
2 1 Element, Wash Heater 04540-100-11-10
3 4 Washer, 1/4"-20 S/S 05311-174-01-00
4 4 Lockwasher, 1/4" Spring 05311-274-01-00
5 4 Nut, 1/4"-20 S/S Hex 05310-274-01-00
6 1 Bracket, Hood Support 05700-000-27-55
7 1 Rivet, 3/16" x 5/8" S/S CTR Flat Head 05320-107-07-00
8 1 Gasket, Hood Support Bracket 05330-200-01-06
9 1 Elbow, 3/4" 90B CU to MNPT Brass 04730-406-42-01
10 1 Tube, 3/4" x 7 1/2" Copper 05700-000-54-86
10a 1 Tube, 3/4" x 6 1/4" Copper (APRB Only) 05700-000-54-87
11 1 Elbow, 3/4" 90B CU to FSPS Brass 04730-406-41-01
12 1 Nipple, 3/4" NPT Close Brass 04730-207-34-00
12a 1 Nipple, 3/4" NPT x 2" Long Brass (APRB Only) 04730-207-46-00
13 1 Probe, High Water (APRB Only) 06680-200-02-68
14 11 Fitting, 1/4" Straight Brass (APRB Only) 04730-011-49-65
15 1 Breather Tube, 1/4" O.D. (APRB Only) 05700-000-29-44
16 1 Elbow, 1/2" 90B CU to FSPS Brass (APRB Only) 04730-406-32-01
17 2 Locknut, Brass 1/2" (APRB Only) 04730-208-03-00
