2-12 4271491-Second Edition
SPECIFICATIONS AND GENERAL INFORMATION
2
Cutting Units
Check and Adjustment Specifications
Reel-to-Bedknife Gap in. (mm) 0.001–0.003 (0.025–0.075)
Reel Bearing Pre-Load
in. (mm) 0.040 (1.27)
Right/Left Reel Leveling Rod—Rod End-to-Nut Face
Measurement (non-spring side)
in. (mm) 1.625 (41.3)
Center Reel Leveling Rod—Rod End-to-Nut Face
Measurement (non-spring side)
in. (mm) 1.00 (25.4)
Reel Leveling Rod—Rod End-to-Collar Face
Measurement (spring side)
in. (mm) 5.250 (133.4)
Reel Leveling Rod—Rod End-to-Nut Face
Measurement (spring side)
in. (mm) 0.125 (3.2)
Repair Specifications
Reel Motor Mounting Screw Torque lb-in. (N·m) 75 (8.5)
Bedknife Mounting Screw Torque
lb-in. (N·m) 90–120 (10.2–13.6)
Bedknife Front Face Height (minimum)
in. (mm) 0.035 (0.9)
Bedknife Front Face Angle (all bedknives)
degrees 5
Bedknife Top Face Angle (rear relief) (all bedknives
except Super Tournament)
degrees 8–10
Super Tournament Bedknife Top Face Angle
(rear relief)
degrees 5–7
Reel Blade Relief Angle
degrees 45
