SPECIFICATIONS AND GENERAL INFORMATION
4271491-Second Edition 2-13
2
Accessories and Miscellaneous
Check and Adjustment Specifications
Turf Groomer Eccentric Mounting Screw Torque lb-ft (N·m) 8–10 (10.8–13.6)
Turf Groomer Belt Tension Link Mounting Screw
Torque
lb-ft (N·m) 20 (27.1)
Repair Specifications
Solid Front Roller Assembly Maximum Rotational
Resistance
lb-in. (N·m) 6 (0.68) Maximum with No End Play
Solid Tube Front Roller Lock Nut Torque
lb-ft (N·m) 10–30 (13.5–40.6)
Solid Tube Front Roller Shaft-to-Bearing Rotational
Resistance
lb-in. (N·m) 0–1 (0–0.11) with No End Play
Solid Tube Front Roller Assembly Maximum
Rotational Resistance
lb-in. (N·m) 6 (0.68) Maximum with No End Play
Grooved Front Roller Lock Nut Torque
lb-ft (N·m) 10–30 (13.5–40.6)
Grooved Front Roller Shaft-to-Bearing Rotational
Resistance
lb-in. (N·m) 0–1 (0–0.11) with No End Play
Grooved Front Roller Assembly Rotational Resistance
lb-in. (N·m) 6 (0.68) Maximum with No End Play
Grooved Disc Roller Assembly Maximum Rotational
Resistance
lb-in. (N·m) 6 (0.68) Maximum with No End Play
Grooved Segmented Front Roller Jam Nut Torque
lb-ft (N·m) 70 (95)
Grooved Segmented Front Roller Assembly Rotational
Resistance
lb-in. (N·m) 6 (0.68) Maximum with No End Play
OPS Mounting Screw Torque
lb-ft (N·m) 25 (39)
Steering Wheel Nut Torque
lb-ft (N·m) 28–30 (38–41)
Rear Axle Assembly Mounting Nut Torque (2WD)
lb-ft (N·m) 150 (203)
Steering Tower Mounting Screw Torque
lb-ft (N·m) 38 (52)
Front Tires
Size 18 x 10.5-8
Type 4-Ply
Air Pressure
psi (bar) 16 (1.1)
Front Wheel Lug Nut Torque
lb-ft (N·m) 80 (108.5)
Rear Tire
Size—2WD 18 x 10.5-8
Size—3WD 18 x 10.5-10
Type 4-Ply
Air Pressure
psi (bar) 20 (1.38)
Rear Wheel Lug Nut Torque (2WD)
lb-ft (N·m) 80 (108.5)
Rear Wheel Mounting Screw Torque (3WD)
lb-ft (N·m) 80 (108.5)
