Jacobsen LF 3800

98
> Change from previous revision
LF 3400 / LF 3800
45.1 Rear Roller
Part Number 1000770
Serial No. All
Item Part No. Qty. Description Serial Numbers/Notes
1
3001654 1 Shaft, Roller
2 3001655 1 Tube, Roller
3 3001656 2 Seal, Grease
4 5000625 2 Bearing, Cup and Cone
5 3000983 2 Seal, Grease
6 3001762 2 Sleeve, Wear
7 445718 2 Locknut, 5/16-18 Stover
8 3000698 2 Washer
1
2
3
4
5
6
7
8
