SPECIFICATIONS 2
13
2.1 VIBRATION LEVEL_________________________________________________________
The mower was tested for hand and arm vibration levels. The operator was in the normal position to drive the vehicle,
with two hands on the steering mechanism. The engine was in operation and the cutting device was in rotation, while
the mower was not moving.
The Machinery Safety Directive 2006/42/EC
By compliance to:
The Lawnmower Standard BS EN ISO 5395-3
Referenced to Hand/Arm: BS EN ISO20643:2008
Information Supplied for Physical Agents Directive 2002/44/EC
By reference to:
Hand/Arm Standards: BS EN ISO 5349-1 (2001)
BS EN ISO 5349-2 (2001)
The mower was tested for Whole Body vibration levels. The operator was in the normal position to drive the vehicle,
with two hands on the steering mechanism. The cutting device was in rotation with the mower driven in a straight line
at 6 Km/hr on a level and cut lawn.
The Machinery Safety Directive 2006/42/EC
By compliance to:
Whole Body EN1032:2003
Information Supplied for Physical Agents Directive 2002/44/EC
By reference to:
Whole Body Standards BS EN ISO 2631-1 (1997)
LF4677
Hand/Arm
Acceleration Level
67963
Maximum Left Hand or Right Hand Accelerations m/s
2
Mean Value of X, Y, Z Aeq
LF4677 67963
0.789 ± 0.6
LF4677
Whole Body
Acceleration Level
67963
Maximum Seat Pad Accelerations m/s
2
Mean Value of X, Y, Z Aeq
LF4677 67963
.295 ± 0.056
