SPECIFICATIONS AND GENERAL INFORMATION
4234520 First Edition 2-7
2
Steering
Cutting Units
Accessories and Miscellaneous
Test and Adjustment Specifications
Steering System Leakage Test—Cylinder Leakage pt (L) Zero–Nominal Amount
Rear Axle Alignment Toe-In Measurement
in. (mm) 0.0625 (1.6)
Rear Axle Spindle Arm-to-Axle Stop Measurement
in. (mm) 0.030–0.060 (0.76–1.5)
Repair Specifications
Steering Wheel Nut lb-ft (N·m) 25–30 (34–41)
Steering Column-to-Steering Unit Screw Torque
lb-in. (N·m) 7.5–10 (10–13)
Steering Unit End Cover-to-Housing Screw Torque
lb-ft (N·m) 20–24 (27–33)
Steering Cylinder Ball Joint-to- Steering Arm Torque
lb-ft (N·m) 40 (54)
Tie Rod Ball Joint-to-Steering Arm Torque
lb-ft (N·m) 30 (41)
Repair Specifications
Blade Retaining Screw lb-ft (N·m) 75 (100)
Adapter Screws
lb-ft (N·m) 35–40 (47–54)
ROPS Mounting Hardware
Mounting Hardware Torque lb-ft (N·m) 135–165 (183–224)
Fuel Tank
Capacity gal (L) 20 (75.7)
Front Tires
Size 26 x 12.00-12
Type 6-Ply
Air Pressure
psi (bar) 16–20 (0.55–0.69)
Mounting Bolt Torque
lb-ft (N·m) 85–95 (115–129)
Rear Tires
Size 23 x 10.50-12
Type 4-Ply
Air Pressure
psi (bar) 10–12 (0.69–0.83)
Mounting Bolt Torque
lb-ft (N·m) 40–50 (54–68)
