Jacobsen R-311T Technical/Repair Manual

SPECIFICATIONS AND GENERAL INFORMATION
4234520 First Edition 2-3
2
Component Location
See Figures 2-4 and 2-5.
!
CAUTION
Figure 2-4: Component Location—Left Side
Become familiar with operator controls, machine
components, and correct operating procedures
before beginning repair procedures.
1 Seat 6 Left Cutting Unit
2 Instrument Panel 7 Right Cutting Unit
3 Steering Wheel 8 Fuel Tank
4 Traction Pedal 9 Battery
5 Center Cutting Unit 10 Brake Pedal
1
2
3
4
5
6
7
8
9
10
TN9962
