3-2 4234520 First Edition
ENGINE
3
Specifications
General Engine Specifications
Repair Specifications
Engine
Manufacturer/Model Kubota
®
Tier 4i/V2403-M-T-E3B
Engine Type 4-stroke, diesel
Fuel Requirement No. 2-D low or ultra low sulfur diesel fuel
(Cetane Rating-45)
Number of Cylinders/Configuration 4, in-line
Displacement
cu in. (cc) 148.5 (2434)
Bore x Stroke
in. (mm) 3.43 x 4.03 (87 x 102.4)
Power Output
hp (kW) 55.9 (41.7) @ 2600 rpm
Firing Order 1-3-4-2
Compression Ratio 23.8:1
Injection Timing (Before T.D.C.) 19°
Cooling System liquid cooled
Cooling System Capacity
qt (L) 8 (7.6)
Idle Speed 800 rpm
Maximum Speed (No Load) 2800 rpm
Oil Sump Capacity
qt (L) 10 (9.5) with filter
Alternator 12 volt, 45 amp
Dry Weight
lb (kg) 414.5 (188)
Specification
Flywheel Drive Plate Screw lb-ft (N·m) 37 (51)
