Technical Specifi cations Manual
Technical Specifi cations
www.jacuzzi.com Page 7
English
Front View Side View Drain/Overfl ow
Bellavista™ Whirlpool Bath
KEY DIMENSIONS
Specifi cations for 6060
6060
(Heater)
(Motor)
(Motor)
(Heater)
Electrical Specifi cations Each component requires a seperate, dedicated GFCI protected circuit
Motor/Pump 120V 20A 60HZ
Heater 120V 15A 60HZ
A
D
B
L
E
W
H
Letter Description English Metric
-
Drain/Motor
Location
Center drain/Right or Left side motor
-
Cutout Template Template Provided P/N P654000
-
Total Weight 1226 lbs 557 kg
-
Floor Loading 49.5 lb/ft
2
242 kg/m
2
-
Operating Gallons
(Min/Max)
80G / 92G 302.8L / 348L
-
Product Weight 160 lbs 73 kg
L
Outer Length 59¾" 1518mm
W
Outer Width 59¾" 1518mm
H
Overall Height 25" 635mm
A
Overfl ow Height
18
⅞"
479mm
B
Long Edge to
Drain Center
14
"
356mm
C
Short Edge to
Drain Center
34 " 879mm
D
Drain Shoe Length
7½
"
191mm
E
Deck Height
2
"
51mm
F
Deck Width
6
"
152mm
G
Service Access
Dimensions
12
" x 18"
305mm x 457mm
I
Floor Cutout for
Drain
12
" x 4"
305mm x 102mm
Suction
Motor
Overfl ow
Heater
3"
I
F
3"
Fitting
A
D
B
Drain/Overfl ow
A
D
B
W
H
(Heater)
(Motor)
E
L
(Motor)
(Motor)
H
W
(Heater)
L
(Heater)
(Motor)
E
Bellavista RH 6060 Bellavista LH 6060 Bellavista RFM 6060
Bellavista LH 6060
Bellavista RH 6060
Bellavista RFM 6060
Control
Panel
W
L
C
(G) Secondary
Service Access
(G) Primary
Service Access
Control
Panel
L
W
C
Suction
Fitting
Heater
I
3"
F
Overfl ow
(G) Service Access
Motor
/
16
9
Motor
Heater
Suction
Fitting
3"
I
F
3"
WL
C
Control
Panel
Overfl ow
