Port Select User can use both RS-232 port or Firmware port to connect flowmeter with
user’s laptops. Caution) The setting must be corrected otherwise user is
unable to download the data.
Memory Clear User can clear all of memory here.
External Memory
Mem Log Info
Wave Data Download the Signal Wave Data
MEMORY
1 . LOG OUTPUT
2 . FORMAT
3 . LOG INTERVAL
4 . LOG TIME SYNC.
5 . LOG ENABLE LOG ENABLE
6 . PORT SELECT 1 . DISABLE
7 . MEMORY CLEAR 2 . ENABLE
MEMORY
1 . LOG OUTPUT
2 . FORMAT
3 . LOG INTERVAL
4 . LOG TIME SYNC.
5 . LOG ENABLE PORT SELECT
6 . PORT SELECT 1 . RS232 PORT
7 . MEMORY CLEAR 2 . FIRMWARE PORT
MEMORY
1 . LOG OUTPUT
2 . FORMAT
3 . LOG INTERVAL
4 . LOG TIME SYNC.
5 . LOG ENABLE MEMORY CLEAR
6 . PORT SELECT 1 . CANCEL
7 . MEMORY CLEAR 2 . CLEAR
MEMORY EXTERNAL MEMORY LOG OUTPUT
1 . INTERNAL MEMORY 1 . LOG OUTPUT 1 . LOG DATE
2 . EXTERNAL MEMORY 2 . LOG INTERVAL 2 . LOG OUTPUT
3 . MEM. LOG INFO. 3 . LOG ENABLE 3 . LOG COUNT
MEM. LOG INFO.
INTERNAL
LOG: ENABLE
FMT: SCFPNTIVE
INTVL: 1 Hour
SYNC: 00:00:00
RS232 PORT
MEMORY
1 . INTERNAL MEMORY EXTERNAL
2 . EXTERNAL MEMORY LOG: DISABLE
3 . MEM. LOG INFO. INTVL: 10Sec
1 . TIME SET
2 . RS-232C
3 . MEMORY 1 . STOP
4 . WAVE DATA 2 . START
DATALOG
WAVE DATA
