Jain Technology XONIC 100L - Page 38

Xonic 100L, 2021
38
REFLECT MODE INSTALLATION
102-TP
TO FLOW COMPUTER UP
STRAP GUIDE
TRANSDUCER
MOUNTING TRACK SERIES
CUSTOMER'S
PIPE
CABLE
FLOW
TRANSDUCERS INSTALLATION
AND MOUNTING TRACKS(REFLECT MODE)
