TRANSDUCERS INSTALLATION
AND MOUNTING TRACKS(DIRECT MODE)
DIRECT MODE INSTALLATION
TO FLOW COMPUTER UP
TRANSDUCER
CLAMP
STRAP GUIDE
TRANSDUCER SET (PAIR)
MOUNTING TRACK SERIES
CUSTOMER'S
PIPE
CABLE
FLOW
CABLE
TO FLOW COMPUTER DOWN
TRANSDUCER
