RM3000 Status Output Word
These 32 bits of status information are outputted when using the g command.
It is in Hexadecimal Word Format
Byte Bit Description
1 7 FWD Mode, Also represents the FWD LED
6 REV Mode, Also represents the REV LED
5 Not used
4 State of the ZERO relay
3 Not used
2 Not used
1 State of the BACKLIGHT
0 State of the BUZZER
2 7 State of the FWD/REV Relay
6 Current Range 10nA+
5 Current Range 100nA+
4 Current Range 1uA+
3 Current Range 10uA+
2 Current Range 100uA+
1 Current Range 1mA+
0 Current Range 10mA+
3 7 A valid reading (e.g. No Errors)
6 Sensitivity Mode Set=High mode
5 Impedance mode Clear=Voltage mode
4 Auto Ranging
3 Memory Full
2 Downloading
1 In the Maths / Setting Menu
0 Mid-Current Entry
4 7 Zeroing
6 Calibrating the DVM
5 Illegal Current
4 Contact Error
3 Out of Range
2 Calibration Error
1 Passed Test Clear=Failed
0 Failed Test Set=Passed
