JandelRM3000Calibration



2. RemovethelidusinggreenOKWkey.Ensuretopushontherelevantslot

positionsasshownintheimagesbelow.



3. EnterattheTerminal:999.99uflzAfterashortdelay,theunitwillchangeto

current999.99uAmps,FWDmode,LOWmodeandhaszeroeditself.



4. ConnectVR2torear4mmsocketsandconnecta1Kresistorplug.Locate

potentiometerVR2.AdjustpotuntiltheexternalDVMreads1V+/‐500uV.

Sendan‘x’.Theunitreplieswiththefollowing:



CalibrationSet1.000V

Factor3372.57Success

SelectFWDChangetoHIandcheckZERO

ThenPressx



Thismessagecouldalsodisplay‘failed’ifthecalculatedfactorisoutofrange

(the1vrefwasout)



5. Theunitnowchangesitsrangeto100uA(althoughtheLCDisnotupdated).

ThereadingontheexternalDVMshouldnowbeadjustedto100mVusing

VR2.Itshouldbepossibletotrimthisintowithin+/‐10uV.



6. Sendanother‘x’.Theunit’sreplyisasfollows:Factorxxxxx.Thistime,ifthe

calculatedfactoristoofarout,theunitwillrefusetotakethesecond‘x’

commandandsothesystemwillneedtobepoweredoff,investigatethe

faultandstartagain.



7. ThesecondlineoftheLCD(voltagereading)nowbecomesimportant.Send:

‘lz’totheunit.Nowcheckthatthe1000mVreadingontheLCDagainstthe

externalDVM.TheLCDreadingneedstobewithin+/‐800uV.Ifnot,the

procedurefrom3)willneedtoberepeatedwithmoreaccuracyandcare.
