- 4 -
G31 Series User's Manual
1.2 Specications-1 (for JW-IG31-MX)
CPU
- LGA775 socket for Intel
®
Core™2 Extreme/ Core™2 Quad/ Core™
2 Duo/ Pentium
®
Dual Core/ Pentium
®
D/Pentium
®
4 (800MHz
FSB)/ Celeron
®
(Conroe-L) Processors
- FSB 1333MHZ/1066MHz/800MHz/
- Hyper Threading Technology
Main Chipset
- Based on G31 + ICH7
- ICH7: Intel FW82801GB
Graphics - Intel Graphics Media Accelerator 3100
Main Memory
- 2 x 240-pin DIMM slots support
- Maximum memory capacity up to 4GB
- Supports Dual Channel DDRII 667/800MHz
BIOS
- Supports Plug&Play
- Supports BIOS ROM Write Protect
- Supports Advanced Power Management ACPI,STR (S3 Optional)
- Supports 1x SYS FAN, 1x CPU FAN
- CPU temperature, Fan speed, System Voltage monitoring
I/O Chipset - Onboard Winbond W83627
Integrated Ports
- 1 x PS/2 Keyboard port
- 1 x PS/2 Mouse port
- 1 x VGA port
- 1 x Debug LED (Optional)
- 1 x SPDIF IN, 1 x SPDIF Out port (Optional)
- 1 x RJ45 port
- 8 x USB 2.0 ports, USB 1.1 is compliant
- 1 x eSATA port
- 1 x IR port (optional)
- 4 x SATA ports by ICH7 , Maximum Speed to 3GB/s
- 1 x IDE connector, 2 x IDE devices could be connected,
Supports ATA 66/100
- 1 x Floppy Drive, supports 360K/720K/1.2M/1.44M/2.88M oppy disk
Sound
- Onboard ALC883 Chipset
- Supports 6/8 channel HD Audio,24 bit Audio Codec
- Positioning Audio Support A3D, I3DL2
- Front Panel Jumper, provides stereo MIC port on front panel
Onboard LAN - Onboard Marwell 88E8056
Expansion Slots
- 1 x PCI Express x16 slot
- 2 x PCI slots
- Support PCI Bus interface v2.2 compliant
Form Factor - Mirco ATX (208*243.8 mm)
