Jandy Pro VSPHP270AUT - Performance Curves; Physical And Operational Specifications

Page 18
ENGLISH
Jandy
®
Pro Series VS PlusHP Pumps
|
Installation & Operation Manual
7.3 Performance Curves
0
5
10
15
20
25
30
35
40
0
10
20
30
40
50
60
70
80
90
100
0 20 40 60 80 100 120 140
PSI
Total Dynamic Head (Feet of Water)
Flow Rate, Gallons Per Minute (GPM)
VSPHP270 Series Pump Performance Curves
3450 RPM
2750 RPM
1730 RPM
1000 RPM
CURVE "A"
CURVE "C"
CURVE "B"
7.4 Physical and Operational Speci cations
7.4.1 Pump Speci cations
Model No. HP Voltage Max Watts Pipe Size Carton Weight Overall Length 'A'
VSPHP270 0.25-2.7 230VAC 2,250W 2½ - 3” 50lbs. 303/8"
7.4.3 PHP Pump Dimensions
9 1/8"
(232 mm)
8 7/8"
(226 mm)
9"
(229 mm)
31"
(788 mm)
11 3/8"
(289 mm)
13 7/8"
(353 mm)
14 1/8"
(378 mm)
Bolt Holes, Center to Center
Front Edge of Union
to Center of Bolt Holes
