Jandy
®
Pro Series VS PlusHP Pumps
|
Installation & Operation Manual
1.2 Pool Pump Suction Entrapment Prevention Guidelines
WARNING
Pump suction is hazardous and can trap and drown or disembowel bathers. Do not use or operate
swimming pools, spa, or hot tubs if a suction outlet cover is missing, broken, or loose. The following
guidelines provide information for pump installation that minimizes the risk of injury to users of pools, spas, and
hot tubs:
Entrapment Protection - The pump suction system must provide protection against the hazards of suction
entrapment.
Suction Outlet Covers - All suction outlets must have correctly installed, screw-fastened covers in place. All
suctionoutlet(drain)assembliesandtheircoversmustbeproperlymaintained.Suctionoutlets(drain)assemblies
andtheircoversmustbelisted/certiedtothelatestversionofANSI
®
/ASME
®
A112.19.8 or its successor standard,
ANSI/APSP-16. They must be replaced if cracked, broken, or missing.
Number of Suction Outlets Per Pump-Provideatleasttwo(2)hydraulically-balancedmaindrains,withcovers,
assuctionoutletsforeachcirculatingpumpsuctionline.Thecentersofthemaindrains(suctionoutlets)onany
one(1)suctionlinemustbeatleastthree(3)feetapart,centertocenter.SeeFigure1.
The system mustbebuilttoincludeatleasttwo(2)suctionoutlets(drains)connectedtothepumpwhenever
thepumpisrunning.However,iftwo(2)maindrainsrunintoasinglesuctionline,thesinglesuctionlinemaybe
equippedwithavalvethatwillshutoffbothmaindrainsfromthepump.Thesystemshallbeconstructedsuchthat
it shall not allow for separate or independent shutoff or isolation of each drain. See Figure 1.
Morethanone(1)pumpcanbeconnectedtoasinglesuctionlineaslongastherequirementsabovearemet.
Water Velocity - The maximum water velocity through the suction outlet assembly and its cover for any suction
outletmustnotexceedthesuctionttingassemblyandit’scover’smaximumdesignowrate.Thesuctionoutlet
(drain)assemblyanditscovermustcomplywiththelatestversionofANSI/ASMEA112.19.8,thestandardfor
Suction Fittings For Use in Swimming Pools, Wading Pools, Spas, and Hot Tubs, or its successor standard, ANSI/
APSP-16.
If100%ofthepump’sowcomesfromthemaindrainsystem,themaximumwatervelocityinthepumpsuction
hydraulicsystemmustbesix(6)feetpersecondorless,evenifone(1)maindrain(suctionoutlet)iscompletely
blocked.Theowthroughtheremainingmaindrain(s)mustcomplywiththelatestversionofANSI/ASME
A112.19.8 or its successor standard, ANSI/APSP-16, the standard for Suction Fittings For Use in Swimming
Pools, Wading Pools, Spas, and Hot Tubs.
Testing and Certication - Suction outlet assemblies and their covers must have been tested by a nationally
recognized testing laboratory and found to comply with the latest version of ANSI/ASME A112.19.8 or its
successor standard, ANSI/APSP-16, the standard for Suction Fittings For Use in Swimming Pools, Wading Pools,
Spas, and Hot Tubs.
Fittings-Fittingsrestrictow;forbestefciencyusefewestpossiblettings(butatleasttwo(2)suctionoutlets).
Avoidttingswhichcouldcauseanairtrap.
PoolcleanersuctionttingsmustconformtoapplicableInternationalAssociationofPlumbingandMechanical
Ofcials(IAPMO)standards.
SUCTION HAZARD. Can cause serious injury or death. Do not use this pump for
wading pools, shallow pools or spas containing bottom drains, unless the pump is
connected to at least two (2) functioning suction outlets.
WARNING
