janitza optec UMG-96 - Indicating range and accuracy

Page 28 = Peak value = Minimum value = Supply
Indicating range and accuracy
Quantity Indicating range Measuring range
1)
Accuracy
5)
Meas. and supply voltage 196 .. 275V
Voltage L-N 0 .. 34kV 196 .. 275V +-1,0% rng
Voltage L-L 0 .. 60kV 340 .. 476V +-2,0% rng
Current 0,00 .. 9,99kA 0,02 .. 5,00A +-1,0% rng
Current in N 0,00 .. 9,99kA 0,03 .. 15,00A +-3,0% rng
Real power consumption, sum 0,00W .. 99,9MW 3,2W .. 1,375kW +-1,5% rng
Real power, supply, sum -0,00W .. -99,9MW -3,2W .. -1,375kW +-1,5% rng
Apparent power, sum 0,00VA .. 99,9MVA 3,2VA ..1,375kVA +-1,5% rng
Reactive power (Q
0
), sum 0,00var .. 99,9Mvar 3,2var..1,375kvar +-1,5% rng
Meas. and auxiliary voltage 98 .. 140V
Voltage L-N 0 .. 34kV 98 .. 140V +-1,0% rng
Voltage L-L 0 .. 60kV 170 .. 242V +-2,0% rng
Current 0,00 .. 9,99kA 0,02 .. 5,00A +-1,0% rng
Current in N 0,00 .. 9,99kA 0,03 .. 15,00A +-3,0% rng
Real power, consumption, sum 0,00W .. 99,9MW 1,6W .. 700W +-1,5% rng
Real power, supply, sum -0,00W .. -99,9MW -1,6W .. -700W +-1,5% rng
Apparent power, sum 0,00VA .. 99,9MVA 1,6VA .. 700VA +-1,5% rng
Reactive power (Q
0
), sum 0,00var .. 99,9Mvar 1,6var .. 700var +-1,5% rng
Meas. and auxiliary
voltage 49 .. 76V
Voltage L-N 0 .. 34kV 49 .. 76V +-1,0% rng
Voltage L-L 0 .. 60kV 85 .. 132V +-2,0% rng
Current 0,00 .. 9,99kA 0,02 .. 5,00A +-1,0% rng
Current in N 0,00 .. 9,99kA 0,03 .. 15,00A +-3,0% rng
Real power, consumption, sum 0,00W .. 99,9MW 0,8W .. 380W +-1,5% rng
Real power, supply, sum -0,00W .. -99,9MW -0,8W .. -380W +-1,5% rng
Apparent power, sum 0,00VA .. 99,9MVA 0,8VA .. 380VA +-1,5% rng
Reactive power (Q
0
), sum 0,00var .. 99,9Mvar 0,8var .. 380var +-1,5% rng
cos(phi) 0,00i .. 1.00 .. 0,00k
2)
Frequency (voltage) 45,0 .. 65,0Hz +-1,5% rdg
Reactive energy, inductive
v4) < 10 0..999 999 9.99kvarh class 2
3)
v
4)
< 100 0..999 999 99.9kvarh class 2
3)
v
4)
>= 100 0..999 999 999kvarh class 2
3)
Real energy, consumption
v
4)
< 10 0..999 999 9.99kWh class 2
3)
v
4)
< 100 0..999 999 99.9kWh class 2
3)
v
4)
>= 100 0..999 999 999kWh class 2
3)
Energying hours counter 0..999 999 999h +-2minutes/day
1)
Measuring range with scale factor = 1, (Current transformer = 5/5A, 1/1A)
2)
If the measured apparent power is in the range of 1% .. 100% of the measuring range, the cos(phi) is displayed with an accuracy of +/- 3%.
3)
Accuracy class according to DIN EN61036:2001-01, VDE0418part 7, IEC61036:1996 + A1:2000
4)
v = vi * vu, vi = Current transformer ration. Example: 200/5A -> vi = 40
vu = Voltage transformer ratio. Example: 1000/100V -> vu = 10
5)
In the range of -10..18°C and 28..55°C an additional inaccuracy of +-0,5‰ omv per K must be mentioned.
