Modbus address list
Address list
Frequently required readings
Address Format RD/WR Designation Unit Note
19000 float RD _G_ULN[0] V Voltage L1-N
19002 float RD _G_ULN[1] V Voltage L2-N
19004 float RD _G_ULN[2] V Voltage L3-N
19006 float RD _G_ULL[0] V Voltage L1-L2
19008 float RD _G_ULL[1] V Voltage L2-L3
19010 float RD _G_ULL[2] V Voltage L3-L1
19012 float RD _G_ILN[0] A Apparent current, L1-N
19014 float RD _G_ILN[1] A Apparent current, L2-N
19016 float RD _G_ILN[2] A Apparent current, L3-N
19018 float RD _G_I_SUM3 A Vector sum; IN=I1+I2+I3
19020 float RD _G_PLN[0] W Real power L1-N
19022 float RD _G_PLN[1] W Real power L2-N
19024 float RD _G_PLN[2] W Real power L3-N
19026 float RD _G_P_SUM3 W Psum3=P1+P2+P3
19028 float RD _G_SLN[0] VA Apparent power L1-N
19030 float RD _G_SLN[1] VA Apparent power L2-N
19032 float RD _G_SLN[2] VA Apparent power L3-N
19034 float RD _G_S_SUM3 VA Sum; Ssum3=S1+S2+S3
19036 float RD _G_QLN[0] var Reactive power L1 (fundamental comp.)
19038 float RD _G_QLN[1] var Reactive power L2 (fundamental comp.)
19040 float RD _G_QLN[2] var Reactive power L3 (fundamental comp.)
19042 float RD _G_Q_SUM3 var Qsum3=Q1+Q2+Q3 (fundamental comp.)
19044 float RD _G_COS_PHI[0] - CosPhi; UL1 IL1 (fundamental comp.)
19046 float RD _G_COS_PHI[1] - CosPhi; UL2 IL2 (fundamental comp.)
19048 float RD _G_COS_PHI[2] - CosPhi; UL3 IL3 (fundamental comp.)
19050 float RD _G_FREQ Hz Measured frequency
19052 float RD _G_PHASE_SEQ - Rotation field; 1=right, 0=none, -1=left
19054 float RD _G_WH[0] Wh Real energy L1
19056 float RD _G_WH[1] Wh Real energy L2
19058 float RD _G_WH[2] Wh Real energy L3
19060 float RD _G_WH_SUML13 Wh Real energy L1..L3
19062 float RD _G_WH_V[0] Wh Real energy L1, consumed
19064 float RD _G_WH_V[1] Wh Real energy L2, consumed
19066 float RD _G_WH_V[2] Wh Real energy L3, consumed
19068 float RD _G_WH_V_HT_SUML13 Wh Real energy L1..L3, consumed, rate 1
19070 float RD _G_WH_Z[0] Wh Real energy L1, delivered
19072 float RD _G_WH_Z[1] Wh Real energy L2, delivered
19074 float RD _G_WH_Z[2] Wh Real energy L3, delivered
19076 float RD _G_WH_Z_SUML13 Wh Real energy L1..L3, delivered
19078 float RD _G_WH_S[0] VAh Apparent energy L1
19080 float RD _G_WH_S[1] VAh Apparent energy L2
19082 float RD _G_WH_S[2] VAh Apparent energy L3
19084 float RD _G_WH_S_SUML13 VAh Apparent energy L1..L3
19086 float RD _G_QH[0] varh Reaktive energy L1 (fundamental comp.)
19088 float RD _G_QH[1] varh Reaktive energy L2 (fundamental comp.)
19090 float RD _G_QH[2] varh Reaktive energy L3 (fundamental comp.)
19092 float RD _G_QH_SUML13 varh Reaktive energy L1..L3 (fundamental comp.)
19094 float RD _G_IQH[0] varh Reactive energy, inductive, L1 (fundamental comp.)
19096 float RD _G_IQH[1] varh Reactive energy, inductive, L2 (fundamental comp.)
19098 float RD _G_IQH[2] varh Reactive energy, inductive, L3 (fundamental comp.)
19100 float RD _G_IQH_SUML13 varh Reactive energy L1..L3, ind. (fundamental comp.)
19102 float RD _G_CQH[0] varh Reactive energy, capacitive, L1 (fundamental comp.)
19104 float RD _G_CQH[1] varh Reactive energy, capacitive, L2 (fundamental comp.)
19106 float RD _G_CQH[2] varh Reactive energy, capacitive, L3 (fundamental comp.)
19108 float RD _G_CQH_SUML13 varh Reactive energy L1..L3, cap. (fundamental comp.)
19110 float RD _G_THD_ULN[0] % Harmonic, THD,U L1-N
19112 float RD _G_THD_ULN[1] % Harmonic, THD,U L2-N
19114 float RD _G_THD_ULN[2] % Harmonic, THD,U L3-N
19116 float RD _G_THD_ILN[0] % Harmonic, THD,I L1
19118 float RD _G_THD_ILN[1] % Harmonic, THD,I L2
19120 float RD _G_THD_ILN[2] % Harmonic, THD,I L3
