janitza UMG 511 - Measurement Values (200 ms Window)

Address Format Designation Unit Note
UMG 511
14
Modbus address list
Messwerte (200ms Messfenster)
3793 float _THD_ULL[0] % Harmonics, THD; U, L1-L2
3795 float _THD_ULL[1] % Harmonics, THD; U, L2-L3
3797 float _THD_ULL[2] % Harmonics, THD; U, L3-L1
3799 float _ZHD_ULL[0] % Interharmonics, U L1-L2
3801 float _ZHD_ULL[1] % Interharmonics, U L2-L3
3803 float _ZHD_ULL[2] % Interharmonics, U L3-L1
3805 float _THD_ULN[0] % Harmonics, THD; U, L1-N
3807 float _THD_ULN[1] % Harmonics, THD; U, L2-N
3809 float _THD_ULN[2] % Harmonics, THD; U, L3-N
3811 float _THD_ULN[3] % Harmonics, THD; U, L4-N
3813 float _THD_IL[0] % Harmonics, THD; I, L1
3815 float _THD_IL[1] % Harmonics, THD; I, L2
3817 float _THD_IL[2] % Harmonics, THD; I, L3
3819 float _THD_IL[3] % Harmonics, THD; I, L4
3821 float _ZHD_ULN[0] % Interharmonics, ZHD; U, L1
3823 float _ZHD_ULN[1] % Interharmonics, ZHD; U, L1
3825 float _ZHD_ULN[2] % Interharmonics, ZHD; U, L1
3827 float _ZHD_ULN[3] % Interharmonics, ZHD; U, L1
3829 float _ZHD_ILN[0] % Interharmonics, ZHD; I, L1
3831 float _ZHD_ILN[1] % Interharmonics, ZHD; I, L2
3833 float _ZHD_ILN[2] % Interharmonics, ZHD; I, L3
3835 float _ZHD_ILN[3] % Interharmonics, ZHD; I, L4
3837 float _KFACT[0] K-Factor; L1
3839 float _KFACT[1] K-Factor; L2
3841 float _KFACT[2] K-Factor; L3
3843 float _KFACT[3] K-Factor; L4
3845 float _ULN[0] V Voltage L1-N
3847 float _ULN[1] V Voltage L2-N
3849 float _ULN[2] V Voltage L3-N
3851 float _ULN[3] V Voltage L4-N
3853 float _ILN[0] A Apparent current, L1
3855 float _ILN[1] A Apparent current, L2
3857 float _ILN[2] A Apparent current, L3
3859 float _ILN[3] A Apparent current, L4
3861 float _PLN[0] W Real power, L1
3863 float _PLN[1] W Real power, L2
3865 float _PLN[2] W Real power, L3
3867 float _PLN[3] W Real power, L4
3869 float _QLN[0] var Mains frequency power factor, L1
3871 float _QLN[1] var Mains frequency power factor, L2
3873 float _QLN[2] var Mains frequency power factor, L3
3875 float _QLN[3] var Mains frequency power factor; L4
3877 float _SLN[0] VA Apparent power, L1
3879 float _SLN[1] VA Apparent power, L2
3881 float _SLN[2] VA Apparent power, L3
3883 float _SLN[3] VA Apparent power, L4
3885 float _DLN[0] VA Distortion power factor; L1
3887 float _DLN[1] VA Distortion power factor; L2
3889 float _DLN[2] VA Distortion power factor; L3
3891 float _DLN[3] VA Distortion power factor; L4
3893 float _PFLN[0] Power Factor; L1
3895 float _PFLN[1] Power Factor; L2
3897 float _PFLN[2] Power Factor; L3
3899 float _PFLN[3] Power Factor; L4
3901 float _ULL[0] V Phase conductor voltage; L1-L2
3903 float _ULL[1] V Phase conductor voltage; L2-L3
3905 float _ULL[2] V Phase conductor voltage; L3-L1
3907 float _ULL_RE[0] V Phase conductor voltage real part; L1-L2
3909 float _ULL_RE[1] V Phase conductor voltage real part; L2-L3
