janitza UMG 511 User Manual

Address Format Designation Unit Note
UMG 511
16
Modbus address list
4017 - - -
4019 - - -
4021 float _IL_CF[0] - Crest factor, I L1
4023 float _IL_CF[1] - Crest factor, I L1
4025 float _IL_CF[2] - Crest factor, I L2
4027 float _IL_CF[3] - Crest factor, I L3
4029 float _ULN_CF[0] - Crest factor, U L1-N
4031 float _ULN_CF[1] - Crest factor, U L2-N
4033 float _ULN_CF[2] - Crest factor, U L3-N
4035 float _ULN_CF[3] - Crest factor, U L4-N
4037 float _ULL_CF[0] - Crest factor, U L1-L2
4039 float _ULL_CF[1] - Crest factor, U L2-L3
4041 float _ULL_CF[2] - Crest factor, U L3-L1
4043 float _IL_NEG_PEAK[0] A Peak value negative, I L1
4045 float _IL_NEG_PEAK[1] A Peak value negative, I L2
4047 float _IL_NEG_PEAK[2] A Peak value negative, I L3
4049 float _IL_NEG_PEAK[3] A Peak value negative, I L4
4051 float _ULN_NEG_PEAK[0] V Peak value negative, U L1-N
4053 float _ULN_NEG_PEAK[1] V Peak value negative, U L2-N
4055 float _ULN_NEG_PEAK[2] V Peak value negative, U L3-N
4057 float _ULN_NEG_PEAK[3] V Peak value negative, U L4-N
4059 float _IL_POS_PEAK[0] A Peak value positive, I L1
4061 float _IL_POS_PEAK[1] A Peak value positive, I L2
4063 float _IL_POS_PEAK[2] A Peak value positive, I L3
4065 float _IL_POS_PEAK[3] A Peak value positive, I L4
4067 float _ULN_POS_PEAK[0] V Peak value positive, U L1-N
4069 float _ULN_POS_PEAK[1] V Peak value positive, U L2-N
4071 float _ULN_POS_PEAK[2] V Peak value positive, U L3-N
4073 float _ULN_POS_PEAK[3] V Peak value positive, U L4-N
4075 float _IL_PEAK_PEAK[0] A Peak-peak value, I L1
4077 float _IL_PEAK_PEAK[1] A Peak-peak value, I L2
4079 float _IL_PEAK_PEAK[2] A Peak-peak value, I L3
4081 float _IL_PEAK_PEAK[3] A Peak-peak value, I L4
4083 float _ULN_PEAK_PEAK[0] V Peak-peak value, U L1-N
4085 float _ULN_PEAK_PEAK[1] V Peak-peak value, U L2-N
4087 float _ULN_PEAK_PEAK[2] V Peak-peak value, U L3-N
4089 float _ULN_PEAK_PEAK[3] V Peak-peak value, U L4-N
4091 float _IL_UNDER[0] % Under difference, I L1
4093 float _IL_UNDER[1] % Under difference, I L2
4095 float _IL_UNDER[2] % Under difference, I L3
4097 float _IL_UNDER[3] % Under difference, I L4
4099 float _ULN_UNDER[0] % Under difference, U L1 (61000-4-30)
4101 float _ULN_UNDER[1] % Under difference, U L2 (61000-4-30)
4103 float _ULN_UNDER[2] % Under difference, U L3 (61000-4-30)
4105 float _ULN_UNDER[3] % Under difference, U L4 (61000-4-30)
4107 float _IL_OVER[0] % Over difference, I L1
4109 float _IL_OVER[1] % Over difference, I L2
4111 float _IL_OVER[2] % Over difference, I L3
4113 float _IL_OVER[3] % Over difference, I L4
4115 float _ULN_OVER[0] % Over difference, U L1 (61000-4-30)
4117 float _ULN_OVER[1] % Over difference, U L2 (61000-4-30)
4119 float _ULN_OVER[2] % Over difference, U L3 (61000-4-30)
4121 float _ULN_OVER[3] % Over difference, U L4 (61000-4-30)
4123 float _ULL_NEG_PEAK[0] V Peak value negative, U L1-L2
4125 float _ULL_NEG_PEAK[1] V Peak value negative, U L2-L3
4127 float _ULL_NEG_PEAK[2] V Peak value negative, U L3-L1
4129 float _ULL_POS_PEAK[0] V Peak value positive, U L1-L2
4131 float _ULL_POS_PEAK[1] V Peak value positive, U L2-L3
4133 float _ULL_POS_PEAK[2] V Peak value positive, U L3-L1
