janitza UMG 511 User Manual

Address Format Designation Unit Note
UMG 511
19
Modbus address list
4323 float _ULL_UNDER_AVG[2] %
4325 float _ULL_NEG_PEAK_AVG[0] V
4327 float _ULL_NEG_PEAK_AVG[1] V
4329 float _ULL_NEG_PEAK_AVG[2] V
4331 float _ULL_POS_PEAK_AVG[0] V
4333 float _ULL_POS_PEAK_AVG[1] V
4335 float _ULL_POS_PEAK_AVG[2] V
4337 float _ULL_PEAK_PEAK_AVG[0] V
4339 float _ULL_PEAK_PEAK_AVG[1] V
4341 float _ULL_PEAK_PEAK_AVG[2] V
4343 float _U_STERN_AVG V
4345 float _U_SYM_AVG %
4347 float _FREQ_AVG Hz
4349 float _NORM_FREQ_AVG Hz
4351 float _PLN_AVG[0] W
4353 float _PLN_AVG[1] W
4355 float _PLN_AVG[2] W
4357 float _PLN_AVG[3] W
4359 float _P_SUM_AVG W
4361 float _Q_SUM_AVG var
4363 float _QLN_AVG[0] var
4365 float _QLN_AVG[1] var
4367 float _QLN_AVG[2] var
4369 float _QLN_AVG[3] var
4371 float _P_SUM3_AVG W
4373 float _Q_SUM3_AVG var
4375 float _ILN_AVG[0] A
4377 float _ILN_AVG[1] A
4379 float _ILN_AVG[2] A
4381 float _ILN_AVG[3] A
4383 float _SLN_AVG[0] VA
4385 float _SLN_AVG[1] VA
4387 float _SLN_AVG[2] VA
4389 float _SLN_AVG[3] VA
4391 float _I_SUM3_AVG A
4393 float _I_SUM_AVG A
4395 float _S_SUM3_AVG VA
4397 float _S_SUM_AVG VA
4399 float _THD_IL_AVG[0] %
4401 float _THD_IL_AVG[1] %
4403 float _THD_IL_AVG[2] %
4405 float _THD_IL_AVG[3] %
4407 float _ZHD_IL_AVG[0] %
4409 float _ZHD_IL_AVG[1] %
4411 float _ZHD_IL_AVG[2] %
4413 float _ZHD_IL_AVG[3] %
4415 float _ILN_CF_AVG[0] -
4417 float _ILN_CF_AVG[1] -
4419 float _ILN_CF_AVG[2] -
4421 float _ILN_CF_AVG[3] -
4423 float _IN_AVG A
4425 float _IM_AVG A
4427 float _IG_AVG A
4429 float _I_SYM_AVG %
4431 float _ILN_OVER_AVG[0] %
4433 float _ILN_OVER_AVG[1] %
4435 float _ILN_OVER_AVG[2] %
4437 float _ILN_OVER_AVG[3] %
4439 float _ILN_UNDER_AVG[0] %
