Address Format Designation Unit Note
UMG 511
25
Modbus address list
4851 float _ULL_UNDER_MAX[0] %
4853 float _ULL_UNDER_MAX[1] %
4855 float _ULL_UNDER_MAX[2] %
4857 float _ULL_NEG_PEAK_MAX[0] V
4859 float _ULL_NEG_PEAK_MAX[1] V
4861 float _ULL_NEG_PEAK_MAX[2] V
4863 float _ULL_POS_PEAK_MAX[0] V
4865 float _ULL_POS_PEAK_MAX[1] V
4867 float _ULL_POS_PEAK_MAX[2] V
4869 float _ULL_PEAK_PEAK_MAX[0] V
4871 float _ULL_PEAK_PEAK_MAX[1] V
4873 float _ULL_PEAK_PEAK_MAX[2] V
4875 float _U_STERN_MAX V
4877 float _U_SYM_MAX %
4879 float _FREQ_MAX Hz
4881 float _NORM_FREQ_MAX Hz
4883 float _PLN_MAX[0] W
4885 float _PLN_MAX[1] W
4887 float _PLN_MAX[2] W
4889 float _PLN_MAX[3] W
4891 float _P_SUM_MAX W
4893 float _Q_SUM_MAX var
4895 float _QLN_MAX[0] var
4897 float _QLN_MAX[1] var
4899 float _QLN_MAX[2] var
4901 float _QLN_MAX[3] var
4903 float _P_SUM3_MAX W
4905 float _Q_SUM3_MAX var
4907 float _ILN_MAX[0] A
4909 float _ILN_MAX[1] A
4911 float _ILN_MAX[2] A
4913 float _ILN_MAX[3] A
4915 float _SLN_MAX[0] VA
4917 float _SLN_MAX[1] VA
4919 float _SLN_MAX[2] VA
4921 float _SLN_MAX[3] VA
4923 float _I_SUM3_MAX A
4925 float _I_SUM_MAX A
4927 float _S_SUM3_MAX VA
4929 float _S_SUM_MAX VA
4931 float _THD_IL_MAX[0] %
4933 float _THD_IL_MAX[1] %
4935 float _THD_IL_MAX[2] %
4937 float _THD_IL_MAX[3] %
4939 float _ZHD_IL_MAX[0] %
4941 float _ZHD_IL_MAX[1] %
4943 float _ZHD_IL_MAX[2] %
4945 float _ZHD_IL_MAX[3] %
4947 float _ILN_CF_MAX[0] -
4949 float _ILN_CF_MAX[1] -
4951 float _ILN_CF_MAX[2] -
4953 float _ILN_CF_MAX[3] -
4955 float _IN_MAX A
4957 float _IM_MAX A
4959 float _IG_MAX A
4961 float _I_SYM_MAX %
4963 float _ILN_OVER_MAX[0] %
4965 float _ILN_OVER_MAX[1] %
4967 float _ILN_OVER_MAX[2] %
