6
UMG 806 www.janitza.com
8. PC connection 42
8. 1 Connection to a PC 42
9. Operation and button functions 43
9. 1 Controls 43
9. 2 Function buttons 43
9. 3 Operation 43
9. 3. 1 Display mode 43
9. 3. 2 Configuration mode 43
9. 4 Password 43
9. 5 Overview of measuring display (display mode) 44
9. 6 Examples of basic measuring displays 45
9. 7 Examples of energy measurement 46
9. 8 Examples of power quality 46
9. 9 Example of time display 46
9. 10 Example of active EI1 module 46
9. 11 Example of active ED1 module 46
10. Configuration 47
10. 1 Configuration mode 47
10. 2 Configuration 47
10. 2. 1 Configuring the network system 47
10. 2. 2 Configuring the current transformer ratios 48
10. 2. 3 Example: Configuring the current transformer ratios I1-I3 48
10. 2. 4 Example: Configuring the current transformer ratios of
residual current measurement input I5 (700:1) 49
10. 2. 5 Configuring the voltage transformer ratios 50
10. 2. 6 Example: Configuring the voltage transformer ratios 50
10. 2. 7 Configuring the RS-485 interface (Modbus) 51
10. 2. 8 Configuring the Ethernet interface 51
10. 3 Parameter list 52
11. Commissioning 56
11. 1 Supply voltage 56
11. 2 Measured voltage 56
