janitza UMG 806 User Manual

7
UMG 806www.janitza.com
11. 3 Frequency measurement 56
11. 4 Measured current 57
11. 5 Checking the phase assignment 57
11. 6 Checking the power measurement 57
11. 7 Checking measurement 57
11. 8 Checking individual power 57
11. 9 Checking summation power 57
12. Connection example, UMG 806 58
13. Expansion modules 59
13. 1 Module types 59
13. 1. 1 806-EC1 module 59
13. 1. 2 806-ED1 module 59
13. 1. 3 806-EI1 module 59
13. 2 Installing the modules 61
13. 3 Front / side views 62
13. 3. 1 806-EC1 module 62
13. 3. 2 806-ED1 module 62
13. 3. 3 806-EI1 module 63
13. 4 Connection examples 63
13. 4. 1 806-ED1 module 63
13. 4. 2 806-EI1 module 63
13. 5 Module detection 64
13. 6 Display examples 64
13. 6. 1 ED1 module 64
13. 6. 2 EI1 module 64
13. 7 EC1 module 64
13. 7. 1 Front LEDs and reset button 64
13. 7. 2 Configuring the Ethernet interface 65
13. 8 Relay outputs of modules ED1
and EI1 66
13. 8. 1 Automatic alarm control
(Example for EI1-RO1) 66
13. 8. 2 Manual control via Modbus addresses 67
13. 8. 3 Table "Parameters of the alarm elements" - addresses (412, 422, 432, 442) 68
13. 8. 4 Alarm elements and units of the alarm limit values 69
