Janome MC400E - Oiling the Machine (2); Oiling the oil wick; Oiling the lower shaft supporter (front and rear)

32
MC450e
w
Slide the cover on the top rear side of the machine.
Oil the oil wick inside of the machine.
Cover
Oil wick
Oil the wick
Oiling the Machine (2)
Remove the thread cutter cover (refer to page 1).
Oil the arrow point as indicated.
Oil the lower shaft supporter (front)
Stand the machine so that the handwheel side comes to
the underside of the machine.
Remove the cover on the underside of the machine with
a screwdriver.
Oil the arrow point(felt) as indicated in the illustration.
Oil the lower shaft supporter (rear)
Cover
